SK-PFKS

PFKS 高速刀把-SK

偏摆跳动≦0.005mm(4倍长)
筒夹采用单边4°角度设计并提高刀把夹持力
采全圆式螺帽,可减少风阻提高稳定度
全系列动平衡

动平衡

SK40 Max.25,000 RPM Or U<= 1gmm
SK50 Max.20,000 RPM Or U<= 1gmm
SK40 Max.25,000 RPM Or U<= 1gmm
SK50 Max.20,000 RPM Or U<= 1gmm

Dimensions

尺寸标示与详细规格比较

Order No.
订购编号
FIGRange ∅d
夹持范围
∅d1∅d2LL1L2Tool Clamping
Depth L3
刀具夹持深度
Nut
螺帽
Screw
调整螺丝
Collet
筒夹
Wrench
扳手
SK40 PFK10-090S21.75~10.027.527.5907130~50CAP-PFK10SPFK-M12SK10PPHS-10-TW275
SK40 PFK10-120S11.75~10.027.5321201017030~50CAP-PFK10SPFK-M12SK10P PHS-10-TW275
SK40 PFK16-090S22.75~16.04040907140~70CAP-PFK16SPFK-M18SK16PPHS-20-RO400
SK40 PFK16-120S22.75~16.0404012010140~70CAP-PFK16SPFK-M18SK16PPHS-20-RO400
Order No.
订购编号
FIGRange ∅d
夹持范围
∅d1∅d2LL1L2Tool Clamping
Depth L3
刀具夹持深度
Nut
螺帽
Screw
调整螺丝
Collet
筒夹
Wrench
扳手
SK50 PFK10-105S11.75~10.027.532105867030~50CAP-PFK10SPFK-M12SK10PPHS-10-TW275
SK50 PFK10-135S11.75~10.027.5321351167030~50CAP-PFK10SPFK-M12SK10PPHS-10-TW275
SK50 PFK10-165S11.75~10.027.5321651467530~50CAP-PFK10SPFK-M12SK10PPHS-10-TW275
SK50 PFK16-105S22.75~16.040401058640~70CAP-PFK16SPFK-M18SK16PPHS-20-RO400
SK50 PFK16-165S12.75~16.040501651469540~70CAP-PFK16SPFK-M18SK16PPHS-20-RO400

备注Remarks

  • 需配合3μ P 筒夹With 3μ P Grade Collet

精密刀柄系列产品

深孔加工・3μm 高精度・减少刀具磨耗

热缩刀柄

Shrink Fit Chuck

10 秒内快速夹换刀・3μm 高精度

油压刀柄

Hydraulic Chuck

重切削・5μm 高精度・超强夹持扭力

HER筒夹刀柄

Her Collet Chuck
