Dimensions
尺寸標示與詳細規格比較
| Order No. 訂購編號 | FIG | ∅D | L1 | L | MACHINING CAPACITY 加工能力 | COMP. 拉伸量 | EXP. 壓縮量 | TAP ADAPTER 適用攻牙套筒 |
|---|---|---|---|---|---|---|---|---|
| BT30 WF12-068 | 1 | 36 | 46 | 68 | M3~M14 | 7.5 | 7.5 | TC312 TC312B |
| BT30 WF12-094 | 1 | 53 | 72 | 94 | M8~M24 | 12.5 | 12.5 | TC820 TC820B |
| Order No. 訂購編號 | FIG | ∅D | L1 | L | MACHINING CAPACITY 加工能力 | COMP. 拉伸量 | EXP. 壓縮量 | TAP ADAPTER 適用攻牙套筒 |
|---|---|---|---|---|---|---|---|---|
| BT40 WF12-073 | 1 | 36 | 46 | 73 | M3~M14 | 7.5 | 7.5 | TC312 TC312B |
| BT40 WF12-135 | 2 | 46 | 110 | 135 | M3~M14 | 15 | 20 | TC312 TC312B |
| BT40 WF12-165 | 2 | 46 | 140 | 165 | M3~M14 | 15 | 20 | TC312 TC312B |
| BT40 WF20-094 | 1 | 53 | 67 | 94 | M8~M24 | 12.5 | 12.5 | TC820 TC820B |
| BT40 WF33-157 | 1 | 78 | 130 | 157 | M14~M36 | 20 | 20 | TC1433 TC1433B |
| Order No. 訂購編號 | FIG | ∅D | L1 | L | MACHINING CAPACITY 加工能力 | COMP. 拉伸量 | EXP. 壓縮量 | TAP ADAPTER 適用攻牙套筒 |
|---|---|---|---|---|---|---|---|---|
| BT50 WF12-084 | 1 | 36 | 46 | 84 | M3~M14 | 7.5 | 7.5 | TC312 TC312B |
| BT50 WF12-135 | 2 | 46 | 97 | 135 | M3~M14 | 15 | 20 | TC312 TC312B |
| BT50 WF12-165 | 2 | 46 | 127 | 165 | M3~M14 | 15 | 20 | TC312 TC312B |
| BT50 WF20-103 | 1 | 53 | 65 | 103 | M8~M24 | 12.5 | 12.5 | TC820 TC820B |
| BT50 WF33-142 | 1 | 78 | 104 | 142 | M14~M36 | 20 | 20 | TC1433 TC1433B |
