Dimensions
尺寸標示與詳細規格比較
| Order No. 訂購編號 | Range ∅d 夾持範圍 | ∅d1 | L | L1 | Tool Clamping Depth L2 刀具夾持深度 | Nut 螺帽 | Collet 筒夾 | Wrench 扳手 |
|---|---|---|---|---|---|---|---|---|
| HSK25E THER16-043 | 0.6~10.0 | 22 | 43 | 33 | max32 | CAP-THER16 | ER16-HP | PHS-20-RO220 |
| Order No. 訂購編號 | Range ∅d 夾持範圍 | ∅d1 | L | L1 | Tool Clamping Depth L2 刀具夾持深度 | Nut 螺帽 | Collet 筒夾 | Wrench 扳手 |
|---|---|---|---|---|---|---|---|---|
| HSK32E THER16-060 | 0.6~10.0 | 22 | 76 | 40 | max40 | CAP-THER16 | ER16-HP | PHS-20-RO220 |
備註 Remarks
- 需配合3μ HP 筒夾 With 3μ HP Grade Collet
- 筒夾夾持為一對一整數值
- HSK25E/HSK32E
