Dimensions
尺寸標示與詳細規格比較
| Order No. 訂購編號 | Range ∅d 夾持範圍 | ∅d1 | L | L1 | Tool Clamping Depth L2 刀具夾持深度 | Nut 螺帽 | Screw 調整螺絲 | Collet 筒夾 | Wrench 扳手 |
|---|---|---|---|---|---|---|---|---|---|
| BT30(BTT30) HER16-060 | 1.0~10.0 | 30 | 60 | 38 | 29~58 | CAP-HER16 | ER-M11 | ER16-HP | PHS-20-RO300 |
| BT30(BTT30) HER16-075 | 1.0~10.0 | 30 | 75 | 53 | 29~58 | CAP-HER16 | ER-M11 | ER16-HP | PHS-20-RO300 |
| BT30(BTT30) HER16-090 | 1.0~10.0 | 30 | 90 | 68 | 29~58 | CAP-HER16 | ER-M11 | ER16-HP | PHS-20-RO300 |
| BT30(BTT30) HER16-120 | 1.0~10.0 | 30 | 120 | 98 | 32~68 | CAP-HER16 | ER-M11 | ER16-HP | PHS-20-RO300 |
| BT30(BTT30) HER20-060 | 1.0~13.0 | 32 | 60 | 38 | 32~68 | CAP-HER20 | ER-M14 | ER20-HP | PHS-20-RO320 |
| BT30(BTT30) HER20-075 | 1.0~13.0 | 32 | 75 | 53 | 32~68 | CAP-HER20 | ER-M14 | ER20-HP | PHS-20-RO320 |
| BT30(BTT30) HER20-090 | 1.0~13.0 | 32 | 90 | 68 | 35~73 | CAP-HER20 | ER-M14 | ER20-HP | PHS-20-RO320 |
| BT30(BTT30) HER20-120 | 1.0~13.0 | 32 | 120 | 98 | 35~73 | CAP-HER20 | ER-M14 | ER20-HP | PHS-20-RO320 |
| BT30(BTT30) HER25-060 | 1.0~16.0 | 40 | 60 | 38 | 35~73 | CAP-HER25 | ER-M18 | ER25-HP | PHS-20-RO400 |
| BT30(BTT30) HER25-075 | 1.0~16.0 | 40 | 75 | 53 | 35~73 | CAP-HER25 | ER-M18 | ER25-HP | PHS-20-RO400 |
| BT30(BTT30) HER25-090 | 1.0~16.0 | 40 | 90 | 68 | 35~73 | CAP-HER25 | ER-M18 | ER25-HP | PHS-20-RO400 |
| BT30(BTT30) HER25-120 | 1.0~16.0 | 40 | 120 | 98 | 41~78 | CAP-HER25 | ER-M18 | ER25-HP | PHS-20-RO400 |
| BT30(BTT30) HER32-060 | 2.0~20.0 | 50 | 60 | 38 | 41~78 | CAP-HER32 | ER-M22 | ER32-HP | PHS-20-RO500 |
| BT30(BTT30) HER32-075 | 2.0~20.0 | 50 | 75 | 53 | 41~78 | CAP-HER32 | ER-M22 | ER32-HP | PHS-20-RO500 |
| BT30(BTT30) HER32-090 | 2.0~20.0 | 50 | 90 | 68 | 41~78 | CAP-HER32 | ER-M22 | ER32-HP | PHS-20-RO500 |
| Order No. 訂購編號 | Range ∅d 夾持範圍 | ∅d1 | L | L1 | Tool Clamping Depth L2 刀具夾持深度 | Nut 螺帽 | Screw 調整螺絲 | Collet 筒夾 | Wrench 扳手 |
|---|---|---|---|---|---|---|---|---|---|
| BT40(BTT40) HER16-075 | 1.0~10.0 | 30 | 75 | 48 | 29~58 | CAP-HER16 | ER-M11 | ER16-HP | PHS-20-RO300 |
| BT40(BTT40) HER16-090 | 1.0~100 | 30 | 90 | 63 | 29~58 | CAP-HER16 | ER-M11 | ER16-HP | PHS-20-RO300 |
| BT40(BTT40) HER16-120 | 1.0~10.0 | 30 | 120 | 93 | 29~58 | CAP-HER16 | ER-M11 | ER16-HP | PHS-20-RO300 |
| BT40(BTT40) HER16-150 | 1.0~10.0 | 30 | 150 | 123 | 29~58 | CAP-HER16 | ER-M11 | ER16-HP | PHS-20-RO300 |
| BT40(BTT40) HER20-075 | 1.0~13.0 | 32 | 75 | 48 | 32~68 | CAP-HER20 | ER-M14 | ER20-HP | PHS-20-RO320 |
| BT40(BTT40) HER20-090 | 1.0~13.0 | 32 | 90 | 63 | 32~68 | CAP-HER20 | ER-M14 | ER20-HP | PHS-20-RO320 |
| BT40(BTT40) HER20-120 | 1.0~13.0 | 32 | 120 | 93 | 32~68 | CAP-HER20 | ER-M14 | ER20-HP | PHS-20-RO320 |
| BT40(BTT40) HER20-150 | 1.0~13.0 | 32 | 150 | 123 | 32~68 | CAP-HER20 | ER-M14 | ER20-HP | PHS-20-RO320 |
| BT40(BTT40) HER25-075 | 1.0~16.0 | 40 | 75 | 48 | 35~73 | CAP-HER25 | ER-M18 | ER25-HP | PHS-20-RO400 |
| BT40(BTT40) HER25-090 | 1.0~16.0 | 40 | 90 | 63 | 35~73 | CAP-HER25 | ER-M18 | ER25-HP | PHS-20-RO400 |
| BT40(BTT40) HER25-120 | 1.0~16.0 | 40 | 120 | 93 | 35~73 | CAP-HER25 | ER-M18 | ER25-HP | PHS-20-RO400 |
| BT40(BTT40) HER25-150 | 1.0~16.0 | 40 | 150 | 123 | 35~73 | CAP-HER25 | ER-M18 | ER25-HP | PHS-20-RO400 |
| BT40(BTT40) HER32-075 | 2.0~20.0 | 50 | 75 | 48 | 41~78 | CAP-HER32 | ER-M22 | ER32-HP | PHS-20-RO500 |
| BT40(BTT40) HER32-090 | 2.0~20.0 | 50 | 90 | 63 | 41~78 | CAP-HER32 | ER-M22 | ER32-HP | PHS-20-RO500 |
| BT40(BTT40) HER32-120 | 2.0~20.0 | 50 | 120 | 93 | 41~78 | CAP-HER32 | ER-M22 | ER32-HP | PHS-20-RO500 |
| BT40(BTT40) HER32-150 | 2.0~20.0 | 50 | 150 | 123 | 41~78 | CAP-HER32 | ER-M22 | ER32-HP | PHS-20-RO500 |
| Order No. 訂購編號 | Range ∅d 夾持範圍 | ∅d1 | L | L1 | Tool Clamping Depth L2 刀具夾持深度 | Nut 螺帽 | Screw 調整螺絲 | Collet 筒夾 | Wrench 扳手 |
|---|---|---|---|---|---|---|---|---|---|
| BT50(BTT50) HER16-105 | 1.0~10.0 | 30 | 105 | 67 | 29~58 | CAP-HER16 | ER-M11 | ER16-HP | PHS-20-RO300 |
| BT50(BTT50) HER16-135 | 1.0~10.0 | 30 | 135 | 97 | 29~58 | CAP-HER16 | ER-M11 | ER16-HP | PHS-20-RO300 |
| BT50(BTT50) HER16-165 | 1.0~10.0 | 30 | 165 | 127 | 29~58 | CAP-HER16 | ER-M11 | ER16-HP | PHS-20-RO300 |
| BT50(BTT50) HER20-105 | 1.0~13.0 | 32 | 105 | 67 | 32~68 | CAP-HER20 | ER-M14 | ER20-HP | PHS-20-RO320 |
| BT50(BTT50) HER20-135 | 1.0~13.0 | 32 | 135 | 97 | 32~68 | CAP-HER20 | ER-M14 | ER20-HP | PHS-20-RO320 |
| BT50(BTT50) HER20-165 | 1.0~13.0 | 32 | 165 | 127 | 32~68 | CAP-HER20 | ER-M14 | ER20-HP | PHS-20-RO320 |
| BT50(BTT50) HER25-105 | 1.0~16.0 | 40 | 105 | 67 | 35~73 | CAP-HER25 | ER-M18 | ER25-HP | PHS-20-RO400 |
| BT50(BTT50) HER25-135 | 1.0~16.0 | 40 | 135 | 97 | 35~73 | CAP-HER25 | ER-M18 | ER25-HP | PHS-20-RO400 |
| BT50(BTT50) HER25-165 | 1.0~16.0 | 40 | 165 | 127 | 35~73 | CAP-HER25 | ER-M18 | ER25-HP | PHS-20-RO400 |
| BT50(BTT50) HER25-200 | 1.0~16.0 | 40 | 200 | 162 | 35~73 | CAP-HER25 | ER-M18 | ER25-HP | PHS-20-RO400 |
| BT50(BTT50) HER32-105 | 2.0~20.0 | 50 | 105 | 67 | 41~78 | CAP-HER32 | ER-M22 | ER32-HP | PHS-20-RO500 |
| BT50(BTT50) HER32-135 | 2.0~20.0 | 50 | 135 | 97 | 41~78 | CAP-HER32 | ER-M22 | ER32-HP | PHS-20-RO500 |
| BT50(BTT50) HER32-165 | 2.0~20.0 | 50 | 165 | 127 | 41~78 | CAP-HER32 | ER-M22 | ER32-HP | PHS-20-RO500 |
| BT50(BTT50) HER32-200 | 2.0~20.0 | 50 | 200 | 162 | 41~78 | CAP-HER32 | ER-M22 | ER32-HP | PHS-20-RO500 |
備註 Remarks
- 需配合3µ HP筒夾 With 3µ HP Grade Collet
- 若需出水型刀把，請參考選用說明
- 筒夾夾持為 一對一整數值
- BT30/BT40/BT50
