BT小徑刀把(刀桿)

BT-THER

THER 小徑刀把-BT

BT30/BT40/BT50
小徑設計，可進行深孔端銑，鑽鉸孔及清角加工
偏擺跳動≦0.005mm（4倍長）
採全圓式螺帽可減少風阻提高穩定度並可對應中心出水
筒夾搭配標準ER系統，泛用性高
全系列使用軸承扳手
全系列動平衡

動平衡

Parfaite Image BT30/BT40 Max.25,000 RPM Or U<= 1gmm
Parfaite Image BT50 Max.20,000 RPM Or U<= 1gmm
Parfaite Image BT30/BT40 Max.25,000 RPM Or U<= 1gmm
Parfaite Image BT50 Max.20,000 RPM Or U<= 1gmm
規格書下載 性能特色

Dimensions

尺寸標示與詳細規格比較

Parfaite Image
Order No.
訂購編號		Range ∅d
夾持範圍		∅d1∅d2LL1L2Tool Clamping
Depth L3
刀具夾持深度		Nut
螺帽		Screw
調整螺絲		Collet
筒夾		Wrench
扳手
BT30(BTT30) THER11-1001.0~7.01620.91007873.219~48 CAP-THER11ER-M8 ER11-HPPHS-20-RO160
BT30(BTT30) THER16-1001.0~7.02226.51007873.229~58 CAP-THER16ER-M11 ER16-HPPHS-20-RO220
Order No.
訂購編號		Range ∅d
夾持範圍		∅d1∅d2LL1L2Tool Clamping
Depth L3
刀具夾持深度		Nut
螺帽		Screw
調整螺絲		Collet
筒夾		Wrench
扳手
BT40(BTT40) THER11-1001.0~7.01620.21007365.319~48 CAP-THER11ER-M8 ER11-HP PHS-20-RO160
BT40(BTT40) THER11-1301.0~7.01622.813010395.319~48 CAP-THER11ER-M8 ER11-HP PHS-20-RO160
BT40(BTT40) THER11-1601.0~7.01625.5160133125.319~48 CAP-THER11ER-M8 ER11-HPPHS-20-RO160
BT40(BTT40) THER16-1001.0~10.02226.11007368.229~58 CAP-THER16ER-M11 ER16-HPPHS-20-RO220
BT40(BTT40) THER16-1301.0~10.02228.713010398.229~58 CAP-THER16ER-M11 ER16-HPPHS-20-RO220
BT40(BTT40) THER16-1601.0~10.02231.3160133128.229~58 CAP-THER16ER-M11 ER16-HP PHS-THER16-R022
Order No.
訂購編號		Range ∅d
夾持範圍		∅d1∅d2LL1L2Tool Clamping
Depth L3
刀具夾持深度		Nut
螺帽		Screw
調整螺絲		Collet
筒夾		Wrench
扳手
BT50(BTT50) THER11-1001.0~7.01618.71006247.719~48 CAP-THER11ER-M8 ER11-HPPHS-20-RO160
BT50(BTT50) THER11-1301.0~7.01621.31309277.719~48 CAP-THER11ER-M8 ER11-HPPHS-20-RO160
BT50(BTT50) THER11-1601.0~7.01623.9160122107.719~48 CAP-THER11ER-M8 ER11-HP PHS-THER1PHS-20-RO160
BT50(BTT50) THER16-1001.0~10.02224.31006247.729~58 CAP-THER16ER-M11 ER16-HPPHS-20-RO220
BT50(BTT50) THER16-1301.0~10.02226.91309277.729~58 CAP-THER16ER-M11 ER16-HPPHS-20-RO220
BT50(BTT50) THER16-1601.0~10.02229.5160122107.729~58 CAP-THER16ER-M11 ER16-HPPHS-20-RO220

備註 Remarks

  • 需配合3µ HP筒夾 With 3µ HP Grade Collet
  • 若需出水型刀把，請參考選用說明
  • 筒夾夾持為 一對一整數值
  • BT30/BT40/BT50

精密刀把系列產品

深孔加工・3μm 高精度・減少刀具磨耗

熱縮刀把

Shrink Fit Chuck

Shrink Fit Chuck
