Dimensions
尺寸標示與詳細規格比較
| Order No. 訂購編號 | FIG | ∅d | ∅d1 | L | L1 | L2 | L3 | L4 | 鎖緊螺絲 Screw |
|---|---|---|---|---|---|---|---|---|---|
| HSK50A SLE06-065 | 1 | 6 | 25 | 65 | 39 | 18 | 36 | SLA-M6 | |
| HSK50A SLE08-065 | 1 | 8 | 28 | 65 | 39 | 18 | 40 | SLA-M8 | |
| HSK50A SLE10-080 | 1 | 10 | 35 | 80 | 54 | 20 | 50 | SLA-M10 | |
| HSK50A SLE12-080 | 1 | 12 | 41 | 80 | 54 | 22.5 | 55 | SLA-M12 | |
| HSK50A SLE16-080 | 1 | 16 | 48 | 80 | 54 | 24 | 55 | SLA-M12 | |
| HSK50A SLE20-080 | 1 | 20 | 52 | 80 | 54 | 25 | 55 | SLA-M16 |
| Order No. 訂購編號 | FIG | ∅d | ∅d1 | L | L1 | L2 | L3 | L4 | 鎖緊螺絲 Screw |
|---|---|---|---|---|---|---|---|---|---|
| HSK63A SLE06-065 | 1 | 6 | 25 | 65 | 39 | 18 | 36 | SLA-M6 | |
| HSK63A SLE08-065 | 1 | 8 | 28 | 65 | 39 | 18 | 40 | SLA-M8 | |
| HSK63A SLE10-080 | 1 | 10 | 35 | 80 | 54 | 20 | 50 | SLA-M10 | |
| HSK63A SLE12-080 | 1 | 12 | 41 | 80 | 54 | 22.5 | 55 | SLA-M12 | |
| HSK63A SLE16-080 | 1 | 16 | 48 | 80 | 54 | 24 | 55 | SLA-M12 | |
| HSK63A SLE20-080 | 1 | 20 | 52 | 80 | 54 | 25 | 55 | SLA-M16 |
| Order No. 訂購編號 | FIG | ∅d | ∅d1 | L | L1 | L2 | L3 | L4 | 鎖緊螺絲 Screw |
|---|---|---|---|---|---|---|---|---|---|
| HSK100A SLE16-100 | 1 | 16 | 48 | 100 | 71 | 24 | 60 | SLA-M12 | |
| HSK100A SLE20-100 | 1 | 20 | 52 | 100 | 71 | 25 | 60 | SLA-M16 | |
| HSK100A SLE25-100 | 2 | 25 | 57 | 100 | 71 | 24 | 25 | 65 | SLA-M16 |
| HSK100A SLE32-100 | 2 | 32 | 63 | 100 | 71 | 24 | 28 | 67 | SLA-M16 |
| HSK100A SLE40-120 | 2 | 40 | 80 | 120 | 91 | 30 | 32 | 80 | SLA-M20 |
備註 Remarks
- 若需搭配中心出水管，請參考規格表
