SK-PFK

PFK 筒夾刀把-SK

偏擺跳動≦0.005mm(4倍長)
筒夾採用單邊4°角度設計並提高刀把夾持力
採全圓式螺帽,可減少風阻提高穩定度
全系列動平衡

Dimensions

尺寸標示與詳細規格比較

Order No.
訂購編號
FIGRange ∅d
夾持範圍
∅d1∅d2LL1L2Tool Clamping
Depth L3
刀具夾持深度
Nut
螺帽
Screw
調整螺絲
Collet
筒夾
Wrench
扳手
SK40 PFK6-09010.7~6.019.53290716321~35CAP-PFK6PFK-M8SK6P PHS-PFK6
SK40 PFK6-12010.7~6.019.5321201016321~35CAP-PFK6PFK-M8SK6P PHS-PFK6
SK40 PFK10-09021.75~10.027.527.5907130~50CAP-PFK10PFK-M12SK10P PHS-PFK10
SK40 PFK10-12011.75~10.027.5321201017030~50CAP-PFK10PFK-M12SK10P PHS-PFK10
SK40 ER16-09022.75~16.04040907140~70CAP-PFK16PFK-M18SK16P PHS-PFK16
SK40 ER16-12022.75~16.0404012010140~70CAP-PFK16PFK-M18SK16P0 PHS-PFK16
SK40 ER25-09026.0~25.45555907150~70CAP-PFK25PFK-M28SK25P PHS-PFK25
SK40 ER25-12026.0~25.4555512010150~70CAP-PFK25PFK-M28 SK25P PHS-PFK25
Order No.
訂購編號
FIGRange ∅d
夾持範圍
∅d1∅d2LL1L2Tool Clamping
Depth L3
刀具夾持深度
Nut
螺帽
Screw
調整螺絲
Collet
筒夾
Wrench
扳手
SK50 PFK6-10510.7~6.019.532105866321~35CAP-PFK6PFK-M8SK6P PHS-PFK6
SK50 PFK6-13510.7~6.019.5321351169721~35CAP-PFK6PFK-M8SK6P PHS-PFK6
SK50 PFK6-16510.7~6.019.53216514612721~35CAP-PFK6PFK-M8SK6P PHS-PFK6
SK50 PFK10-10511.75~10.027.532105867030~50CAP-PFK10PFK-M12SK10P PHS-PFK10
SK50 PFK10-13511.75~10.027.5321351167030~50CAP-PFK10PFK-M12SK10P PHS-PFK10
SK50 PFK10-16511.75~10.027.5321651467530~50CAP-PFK10PFK-M12SK10P PHS-PFK10
SK50 PFK16-10522.75~10.040401058640~70CAP-PFK16PFK-M18SK16P PH PHS-PFK16
SK50 PFK16-16512.75~10.040501651469540~70CAP-PFK16PFK-M18SK16P PHS-PFK16
SK50 PFK25-10526.0~25.055551058650~85CAP-PFK25PFK-M28SK25P PHS-PFK25
SK50 PFK25-16526.0~25.0555516514650~85CAP-PFK25PFK-M28SK25P PHS-PFK25

備註 Remarks

  • 需配合3μ P 筒夾 With 3μ P Grade Collet
