Dimensions
尺寸標示與詳細規格比較
| Order No. 訂購編號 | FIG | ∅d | ∅d1 | ∅d2 | ∅d3 | L | L1 | L2 | Tool Clamping Depth L3 刀具夾持深度 | L4 | Screw 調整螺絲 |
|---|---|---|---|---|---|---|---|---|---|---|---|
| SK40 CR04-080 | 1 | 4 | 14 | 21 | 80 | 60.9 | 40.7 | min15 | |||
| SK40 CR06-080 | 1 | 6 | 21 | 27 | 80 | 60.9 | 34.3 | 25.5~31.5 | HY06-M5 | ||
| SK40 CR06-130 | 2 | 6 | 21 | 27 | 31.9 | 130 | 110.9 | 38.1 | 25.5~31.5 | 108.1 | HY08-M6 |
| SK40 CR08-080 | 1 | 8 | 21 | 27 | 80 | 60.9 | 34.3 | 30.5~35.5 | HY08-M6 | ||
| SK40 CR08-130 | 2 | 8 | 21 | 27 | 31.9 | 130 | 110.9 | 38.1 | 30.5~35.5 | 108.1 | HY08-M6 |
| SK40 CR10-080 | 1 | 10 | 24 | 32 | 80 | 60.9 | 47 | 36.5~41.5 | HY08-M6 | ||
| SK40 CR10-130 | 2 | 10 | 24 | 32 | 36.4 | 130 | 110.9 | 50.8 | 36.5~41.5 | 108.1 | HY08-M6 |
| SK40 CR10-160 | 2 | 10 | 24 | 32 | 39.6 | 160 | 140.9 | 50.8 | 36.5~41.5 | 138.1 | HY08-M6 |
| SK40 CR12-080 | 1 | 12 | 24 | 32 | 80 | 60.9 | 47 | 41.5~46.5 | HY14-M8 | ||
| SK40 CR12-130 | 2 | 12 | 24 | 32 | 36.4 | 130 | 110.9 | 50.8 | 41.5~46.5 | 108.1 | HY14-M8 |
| SK40 CR12-160 | 2 | 12 | 24 | 32 | 39.6 | 160 | 140.9 | 50.8 | 41.5~46.5 | 138.1 | HY14-M8 |
| Order No. 訂購編號 | FIG | ∅d | ∅d1 | ∅d2 | ∅d3 | L | L1 | L2 | Tool Clamping Depth L3 刀具夾持深度 | L4 | Screw 調整螺絲 |
|---|---|---|---|---|---|---|---|---|---|---|---|
| SK50 CR06-080 | 1 | 6 | 21 | 27 | 80 | 60.9 | 34.3 | 25.5~31.5 | HY06-M5 | ||
| SK50 CR06-130 | 2 | 6 | 21 | 27 | 31.2 | 130 | 110.9 | 38.1 | 25.5~31.5 | 101.4 | HY06-M5 |
| SK50 CR06-160 | 2 | 6 | 21 | 27 | 34.4 | 160 | 140.9 | 38.1 | 25.5~31.5 | 131.4 | HY06-M5 |
| SK50 CR08-080 | 1 | 8 | 21 | 27 | 80 | 60.9 | 34.3 | 30.5~35.5 | HY08-M6 | ||
| SK50 CR08-130 | 2 | 8 | 21 | 27 | 31.2 | 130 | 110.9 | 38.1 | 30.5~35.5 | 101.4 | HY08-M6 |
| SK50 CR08-160 | 2 | 8 | 21 | 27 | 34.4 | 160 | 140.9 | 38.1 | 30.5~35.5 | 131.4 | HY08-M6 |
| SK50 CR10-080 | 1 | 10 | 24 | 32 | 80 | 60.9 | 47 | 36.5~41.5 | HY08-M6 | ||
| SK50 CR10-130 | 2 | 10 | 24 | 32 | 35.7 | 130 | 110.9 | 50.8 | 36.5~41.5 | 101.4 | HY08-M6 |
| SK50 CR10-160 | 2 | 10 | 24 | 32 | 38.9 | 160 | 140.9 | 50.8 | 36.5~41.5 | 131.4 | HY08-M6 |
| SK50 CR12-080 | 1 | 12 | 24 | 32 | 80 | 60.9 | 47 | 41.5~46.5 | HY14-M8 | ||
| SK50 CR12-130 | 2 | 12 | 24 | 32 | 35.7 | 130 | 110.9 | 50.8 | 41.5~46.5 | 101.4 | HY14-M8 |
| SK50 CR12-160 | 2 | 12 | 24 | 32 | 38.9 | 160 | 140.9 | 50.8 | 41.5~46.5 | 131.4 | HY14-M8 |
備註 Remarks
- 刀具柄徑公差h6( h6 Tooling Diameter Tolerance)
- 若需出水型刀把，請參考選用說明
