HSK-A-CR

CR 標準型熱縮刀把-HSK-A

偏擺跳動≦0.003mm (4倍長)
經特殊熱處理製程,可保持最佳精度及壽命
刀具360°全周完整夾持,剛性可大幅提升
超強夾持力,粗精加工皆可對應
全系列動平衡
熱縮機備有高階型/經濟型款式

動平衡

Max.25,000 RPM Or U<= 1gmm
Max.25,000 RPM Or U<= 1gmm

Dimensions

尺寸標示與詳細規格比較

Order No.
訂購編號
FIG∅d∅d1∅d2∅d3LL1L2Tool Clamping
Depth L3
刀具夾持深度
L4Screw
調整螺絲
HSK50A CR04-080141421805440.7min15
HSK50A CR06-080162127805434.325.5~31.5HY06-M5
HSK50A CR08-080182127805434.330.5~35.5HY08-M6
HSK50A CR10-085110243285594736.5~41.5HY08-M6
HSK50A CR12-090112243290644741.5~46.5HY14-M8
HSK50A CR16-0951162734956940.744.5~49.5HY18-M12
Order No.
訂購編號
FIG∅d∅d1∅d2∅d3LL1L2Tool Clamping
Depth L3
刀具夾持深度
L4Screw 調整螺絲
HSK63A CR04-080141421805440.7min15
HSK63A CR06-080162127805434.325.5~31.5HY06-M5
HSK63A CR06-13026212733.513010438.125.5~31.5101.2HY06-M5
HSK63A CR06-16026212738.216013438.125.5~31.5131.2HY06-M5
HSK63A CR08-080182127805434.330.5~35.5HY08-M6
HSK63A CR08-13028212733.513010438.130.5~35.5101.2HY08-M6
HSK63A CR08-16028212738.216013438.130.5~35.5131.2HY08-M6
HSK63A CR10-085110243285594736.5~41.5HY08-M6
HSK63A CR10-130210243237.713010450.836.5~41.5101.2HY08-M6
HSK63A CR10-160210243242.416013450.836.5~41.5131.2HY08-M6
HSK63A CR12-090112243290644741.5~46.5HY14-M8
HSK63A CR12-130212243237.713010450.841.5~46.5101.2HY14-M8
HSK63A CR12-160212243242.416013450.841.5~46.5131.2HY14-M8
HSK63A CR16-0951162734956940.744.5~49.5HY18-M12
HSK63A CR16-130216273440.513010444.544.5~49.5101.2HY18-M12
HSK63A CR16-160216273445.216013444.544.5~49.5131.2HY18-M12
HSK63A CR20-10012033421007453.446.5~51.5HY18-M12
HSK63A CR20-130220334247.213010457.246.5~51.5103.1HY18-M12
HSK63A CR20-160220334248.816013457.246.5~51.5133.1HY18-M12
HSK63A CR25-11512544531158951.552.5~57.5HY25-M16
HSK63A CR25-130125445313010451.552.5~57.5HY25-M16
HSK63A CR25-160125445316013451.552.5~57.5HY25-M16
HSK63A CR32-12013244531209451.555.5~60.5HY25-M16
HSK63A CR32-160132445316013451.555.5~60.5HY25-M16
Order No.
訂購編號
FIG∅d∅d1∅d2∅d3LL1L2Tool Clamping
Depth L3
刀具夾持深度
L4Screw
調整螺絲
HSK100A CR06-085162127855634.325.5~31.5HY06-M5
HSK100A CR06-1302621273213010138.125.5~31.591.5HY06-M5
HSK100A CR06-16026212736.716013138.125.5~31.5121.5HY06-M5
HSK100A CR08-085182127855634.330.5~35.5HY08-M6
HSK100A CR08-1302821273213010138.130.5~35.591.5HY08-M6
HSK100A CR08-16028212736.716013138.130.5~35.5121.5HY08-M6
HSK100A CR10-090110243290614736.5~41.5HY08-M6
HSK100A CR10-130210243236.213010150.836.5~41.591.5HY08-M6
HSK100A CR10-160210243240.916013150.836.5~41.5121.5HY08-M6
HSK100A CR12-095112243295664741.5~46.5HY14-M8
HSK100A CR12-130212243236.213010150.841.5~46.591.5HY14-M8
HSK100A CR12-160212243240.916013150.841.5~46.5121.5HY14-M8
HSK100A CR16-10011627341007140.744.5~49.5HY18-M12
HSK100A CR16-13021627343913010144.544.5~49.591.5HY18-M12
HSK100A CR16-160216273443.716013144.544.5~49.5121.5HY18-M12
HSK100A CR20-10512033421057653.446.5~51.5HY18-M12
HSK100A CR20-130220334245.413010157.246.5~51.591.5HY18-M12
HSK100A CR20-16022033424716013157.246.5~51.5121.5HY18-M12
HSK100A CR25-11512544531158651.552.5~57.5HY25-M16
HSK100A CR25-160225445360.116013155.952.5~57.5121.5HY25-M16
HSK100A CR32-12013244531209151.555.5~60.5HY25-M16
HSK100A CR32-160232445360.116013155.955.5~60.5121.5HY25-M16

備註 Remarks

  • 刀具柄徑公差h6( h6 Tooling Diameter Tolerance)
  • 若需搭配中心出水管,請參考規格表
  • 若需出水型刀把,請參考選用說明
